Panasonic AV-HS400A HD/SD SDI Vision Mixer


The multi-format AV-HS400A live switcher is an all-in-one system that easily integrates into existing HD/SD workflows, flawlessly mixing HD and SD video sources. With a built-in MultiViewer image preview, expandable HD/SD architecture, 3D digital effects and a host of other advanced features, the AVHS400A provides all the functions you need for superb results.



Video Format:

  • SD (576/50i, 480/59.94i),HD (1080/59.94i, 1080/50i, 720/59.94p, 720/50p)


  • 1M/E


  • Video processing:Y:Cb:Cr, 4:2:2 10 bitRGB, 4:4:4 8 bit


  • Four inputs (HD/SD-SDI)
  •  DVI-I x 2

Reference Video:

  • Black burst/TRI (loop through) x 1


  • Standard: Four outputs (PGM x 2, general-purpose x 2, each HD/SD-SDI )
  • Option: A maximum of four outputs (general-purpose x 4), (Up to 2 output boards each board offering 2 outputs) for the following 3 types of boards may be added: analog component x 2, DVI-I/analog component x 1 each, HD/SD-SDI x 2

Reference Output:

  • Reference: Loop through x 1 (Genlock)/ Black burst x 2 (internal synchronization)

Removable Media:

  • SD memory card slot: 1 (for transferring still image files and providing an upgrade capability)

Power Consumption:

  • 98 W

Transport Weight (Kg):

  • 51 Kg

Panasonic AV-HS400A HD/SD SDI Vision Mixer Manual
Panasonic AV-HS400A HD/SD SDI Vision Mixer Spec Sheet
